리튬 이온 전지 용 CNT/Graphene 코팅
Li-ion Battery
Specifications of Products
| Category | Product | Bare CNT | Dispersed Products Particle size(㎛) |
Diluent | CNT Type |
CNT (wt%) |
Graphene (wt%) |
Additive (wt%) |
|||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Diameter (nm) |
Length (㎛) |
D50 | D90 | ||||||||
| Conductive | Cathode | M5N | 8~13 | 50~150 | 3~8 | 10~15 | NMP | MWCNT | 5 | - | 1 |
| M8N | 8~13 | 50~150 | 3~8 | 10~15 | NMP | MWCNT | 8 | 2 | |||
| SCB-H8N | 8~13 | 50~150 | 3~5 | 7~9 | NMP | MWCNT | 5 | 3 | 1.2 | ||
| Anode | D1W | 5~7 | 50~150 | 3~8 | 5~8 | Water | TWCNT | 1 | - | 2.1 | |
| D3W | 5~7 | 50~150 | 3~8 | 5~8 | Water | TWCNT | 3 | - | 3.1 | ||
| S15W | 1.1~1.4 | >5 | 2~4 | 8~12 | Water | SWCNT | 1.5 | - | 1.6 | ||
| Coating Solution for Si |
Anode | E01 | 5~7 | 50~150 | 3~5 | 8~12 | Ethanol | TWCNT | 1 | - | 2 |
| E03 | 5~7 | 50~150 | 5~7 | 10~14 | Ethanol | TWCNT | 3 | - | 6 | ||
| GH05W | rGO-H Graphene | 1~3 | 3~5 | Water | - | 0.5 | 0.5 | ||||
| GN05W | rGO-H Graphene | 1~3 | 3~5 | Water | - | 0.5 | 0.5 | ||||
| Category | Product | Binder | Dilluent | Non-Volatile (wt%) |
|
|---|---|---|---|---|---|
| Viscosity Reducer |
Cathode | SCB-VR8N | Rubber | NMP | 8 |
※ ⑴SWCNT stands for Single Wall CNT ⑵TWCNT(SCB-D Series) stands for Thin Wall CNT ⑶MWCNT stands for Multi Wall CNT
※ According to Customer's request, we can offer the service to change of particle size, solvent, and binder.
※ Values indicated in this data sheet describe typical properties and do not constitute specification limits
CNT / Graphene Coated
on Active Materials
CNT Coated on NCM (Single Crystal)
CNT Coated on NCM (Polycrystalline)
CNT Coated on LFP
CNT Coated on SiOx
CNT Coated on SiC
Graphene Coated on Active Materials
